High voltage and high-efficiency three-phase asynchronous motor
Product Category:
| ■ Power：450 ~ 4500（10kV IC611 4 极 / 4 poles） | ■ Installation method：IM B3 |
| ■ Polarity：2、4、6、8 | ■ Efficiency：Energy Efficiency Level 2 (GB30254-2013) |
| ■ Center height：355、400、450、500、560 | ■ Bearings: ：well-known Chinese brands (foreign brands are optional) |
| ■ Voltage：6 kV/50 Hz, 10 kV/50 Hz | ■ Rated voltage：6/10 kV ±5 % |
| ■ Thermal classification：F-class insulation, B-class temperature rise | ■ Rated voltage：50 Hz±2 % |
| ■ Cooling method：IC611，IC81W，IC01 | ■ Environmental temperature：-20 ºC ~ 40 ºC |
| ■ Protection level：IP23，IP55 | ■ Altitude: not exceeding 1000 meters |
| ■ Shell material: welded steel plate | ■ Working system: continuous working system S1 |
The Beide 1Q.1 series high-voltage high-efficiency three-phase asynchronous motor is a new generation of modular motor products launched by Yinmengda. The efficiency of the entire series of motors meets China's energy efficiency level 2 (GB30254-2013) and uses the proven MICALASTIC ® The insulation system has the characteristics of high efficiency, energy saving, reliable operation, low noise, and compact structure, and can be widely used in various mechanical equipment such as fans, water pumps, compressors, etc.
