1MT8004 IE4 series Flameproof Low Voltage Three-phase Asynchronous Motor
Product Category:Flameproof
| ■ Rated output：1.5 ~ 315 kW |
■ Frame-proof marking：Ex db IIB T4 Gb |
| ■ Frame size：100 ~ 355 | ■ Protect degree：IP55 |
|
■ Voltage and Frequency：380/660V 50Hz, Othercommon voltage can be provide as option design
|
■ Insulation class：F |
| ■ Standard color：RAL7011 | ■ Re-greasing device：FS 160 ~ 355 motor as standard |
|
■ Cooling method：IC411 |
■ Ambient temperature：-20ºC ~ 40ºC as standard |
1MT8004 series flameproof motors is newly designed totally enclosed fan cooling (TEFC) high efficiency motor. This series flameproof motor completely meet the standard of IEC 60079- 0:2017/IEC 60079-1:2017 and GB/T 3836.1-2021/GB/T 3836.2-2021. The type of protection for this motor is Ex db IIB T4 Gb. And its efficiency fulfill efficiency grade IE4 (50Hz) of IEC 60034-30, and also Grade 2 efficiency of GB 18613-2020.
